KFA(S)

4 product code

KFA(S)

KFA(S) is a lubrication component for supplying or distributing oil or grease. Select the configuration according to the lubrication system and operating conditions.

Loading product code list…

Selected code

KFA1-M-W-S3 924

LubricantGrease up to NLGI 2
Operating - voltage24 V

LDT will confirm price, stock and delivery time when the request is received.

Detailed technical content

Select the pump according to the complete system

A lubrication pump should not be selected by pressure or reservoir capacity alone. First determine whether the pump will operate with a single-line lubrication system, a progressive lubrication system or direct supply to lubrication points, and then compare the lubricant type, number of supply points, required flow rate and control method.

Some electric pumps, such as SKF KFG, can be configured for a MonoFlex single-line system or a ProFlex progressive system. Jianhe’s DBS series is designed primarily for progressive-divider systems and can use multiple pump elements for direct supply or distribution through a divider network.

Lubricant, pump elements and flow rate

Pumping capability depends on grease consistency or oil viscosity, ambient temperature and the pump-element design. Two pumps with the same rated pressure may not deliver the same flow rate or be suitable for the same grease.

When a system has multiple branches, check the number of pump elements, the flow from each element and how the outlets are combined. Increasing the number of outlets does not mean that every point will receive enough grease if total system demand exceeds the pump’s capacity.

Power supply, control and monitoring

Depending on the series, a pump may use direct current for mobile machines or alternating current for stationary equipment. Some versions have an integrated controller, level sensor or connection for external control. When replacing a pump, check the voltage, control method, monitoring signals and wiring diagram, not just the mechanical dimensions.

FAQ

Frequently asked questions

Can two lubrication pumps with the same operating pressure be directly interchanged?

No. Pressure is only one parameter. The pump must also match the lubricant type, flow rate, number of pumping elements, reservoir capacity, voltage, control method and downstream system. A pump with similar pressure but different flow or operating principle can underfeed the system or produce an incorrect cycle.

Does selecting the highest-pressure pump always improve the system?

No. Pressure must be sufficient to overcome losses in piping, distributors and lubrication points, but should not greatly exceed what is required. Every system component has its own pressure limit. Select the pump from the calculations and specifications of the complete system, not only the maximum pressure value.

Can one pump be used for both single-line and progressive systems?

It depends on the design. SKF states that KFG can be configured for MonoFlex single-line and ProFlex progressive systems, but not every pump supports both. Check the exact pump configuration, pressure-relief valve, distribution elements and control diagram of the system.

What information besides the pump designation is needed when replacing an old pump?

Provide the lubricant type, voltage, reservoir capacity, number of outlets or pumping elements, required pressure and flow, downstream system type and a photograph of the old nameplate. If the pump has an integrated controller or level sensor, include wiring and control-signal information to avoid selecting the correct mechanical unit with incompatible electrical equipment.
